1. The HL series CNC lathe is a high -rigidity, high -precision CNC diagonal car and driving center;
2. This machine table body, main shaft box, saddle, skateboard, motor seat, bearing seat are all cast in HT300. All casts are kept at the time of warming more than 56 hours, which will benefit from eliminating internal stress and ensuring the stability of the machine tool.
3. The bed body is cast as a whole with a 30 -degree oblique body leak -proof, which greatly improves the stability and cutting rigidity of the machine tool processing.
4. High -rigidity tail seat, using MT5 top, inadvertent axis sleeve, avoiding errors, programming control, hydraulic driving, and more convenient operation.
5. Selective chipping method. Users can choose the right crumbs or rear crumbs in advance to facilitate the user's reasonable use of the space of the factory area.
6. The fins of the fins show the excellent heat dissipation and reach the minimum heat variable position error.
7. Thex/Z axes are compensated by the laser snail distance to ensure the processing accuracy of the machine tool.
8.X/Z axis adopts a linear rail, which has the characteristics of high rigidity, low noise, low friction, and can be used for fast displacement and obtaining the best circular accuracy.
9. Quick displacement X/Z: 20/20/20mm/min.
10.X/Z servo motor uses an absolute detection. It does not need to be re -returned at each processing, which can improve efficiency. At the same time, because there is no limit switch, it can reduce the fault rate and increase the reliability of the machine.
11.X/Z axis servo motor and the screw are directly connected to the precision coupling, which can exclude the connection gap and improve the transmission efficiency.
12. The cutting liquid capacity is 240L, which can quickly discharge the cutting heat. Put it at the bottom of the machine to save space.
13. The main axis adopts a precision -grade diagonal bead bearing high -speed and high -precision, and the standard speed can reach 3500rpm. The machine uses a 15kW spindle motor, and the main shaft is a synchronous strap wheel of the S8M. It does not slip to ensure the utilization rate of the spindle motor power and enhance the cutting rigidity of the main axis.
14. The power distribution box adopts a rear -hanging design to save the space occupying the space and enable the limited space to obtain the maximum use.
15. In order to ensure the quality of the whole machine, the main foreign purchase parts use world -famous manufacturers:
Subdivy of the axle: Japan NSK/NTN
Linear slide: PMI/THK
Rolling screw: PMI/THK
Control System: Faniko/Mitsubishi E80/New Generation
Servo Motor: Faniko/Mitsubishi/New Generation
Note: The above -mentioned supporting manufacturers are designated suppliers in the company. When they are not available in special circumstances, they will be replaced by the same level of products, but the quality standards are not lower than the above suppliers.
